MP365 Planer / Moulder

Starting at
£16,000.00
In stock

* Above price is for the MP365 (MP365EH16S) with variable feed speed, tilting spindle cutter head, 3-phase.

Other configurations vary in price.

Print Add to Compare
4-Sided Moulder and Planer
High Production Four-sided Moulder and Planer with Universal Spindle.
Benefits
  • 4-sided planing and profiling in one pass.
  • Large 4-sided cutting capacity - 360 mm wide x 160 mm high.
  • 5th spindle rotates up to 270 degrees.
Description MP365 Planer / Moulder
For the ultimate in workshop flexibility for producing whatever your client demands, the MP365 gives you the full functionality of a four-sided planer/moulder, plus a fifth spindle cutter that can tilt up to 270 degrees, so you can add additional profiles from any side, or attach sanding or brushing tools to deliver a final finish to your profiled timber.
Read More
I was starting to make tables, and I had customers looking for tongue-in-groove and such. I looked around and did a lot of research on the internet, and the MP360 covered everything - all the bases I needed.
Sandy Crook
Read the Story
Around the World

More Success Stories

Specifications MP365 Planer / Moulder
Specifications
4-sided Moulding Capacity
Max. Width 360 mm
Max. Height 160 mm
2-sided Moulding Capacity
Max. Width 410 mm
Max. Height 230 mm
1-sided Moulding or Thicknessing Capacity
Max. Height 510 mm
Max. Height 230 mm
Features & Options
Number of Horizontal Cutters 2
Number of Spindles 3
Number of Sawdust Extraction Ports 5
Viewing Window Yes
Options Support Rollers
Infeed Table - 2 m
Board Fence Extensions
Rear Fence Extension
Upper Horizontal Cutter
Diameter 88 mm
Width 510 mm
Power 5.5 kW (7.5 HP)
Rotation Speed 6000 RPM / 50 Hz
Max. Cutting Depth 8 mm
Max. Profile Depth 20 mm
Lower Horizontal Cutter
Diameter 72 mm
Width 410 mm
Power 4 kW (5.5 HP)
Rotation Speed 6000 RPM / 50 Hz
Max. Cutting Depth 8 mm
Max. Profile Depth 10 mm (slot drill 15mm)
Vertical Cutters
Spindle Diameter 30 mm
Max. Cutter Height 160 mm
Max. Diameter 160mm (6 1/4")
Power 3 kW (4 HP)
Rotation Speed 6000 RPM / 50Hz
Max. Cutting Depth 30 mm
Standard Vertical Cutters Included
Type TB90
Diameter 90 mm
Height 40 mm
Knife Type HSS
Knife Width 50 mm
Universal Spindle
Diameter 30 mm
Max. Cutter Height 130 mm
Max. Diameter 200 mm
Power 3 kW (4 HP)
Rotation Speed 3000, 6000, 9000 RPM
Tilt 0º - 270º
Power Feed
Feed Motor 0.75 kW (1 HP)
Feed Speed 3 - 15 m/min / 50Hz
Feed Rollers 4 Steel + 1 Polyurethane Rollers
5 Polyurethane Rollers (Optional)
Dimensions & Weight
Length 3660 mm
Width 1125 mm
Height 1430 mm
Weight 1000 kg
Shipment Weight 1120 kg
Machine Standards & Requirements
Total Power 19.25 kW (26 HP)
Electrical Requirements 3-phase, 400 V, 20-32 A
3-phase, 230 V, 32-50 A
Sawdust Collection Port Diameter 4 x 100 mm + 1 x 125 mm
Safety Standards CE
